Fastech Global is the leading Companion Flanges Supplier, Stockists & Supplier, dealer and Exporter in India.Fastech Global is known worldwide for its extensive high quality range of Buttwelded Pipe Fittings.
A flange is an external or internal ridge, or rim, for strength, as the flange of an iron beam such as an I-beam or a T-beam ; or for attachment to another object, as the flange on the end of a pipe, steam cylinder, etc., or on the lens mount of a camera or for a flange of a rail car or tram wheel . Thus flanged wheels are wheels with a flange on one side to keep the wheels from running off the rails . The term "flange" is also used for a kind of tool used to form Companion Flanges. Pipes with Companion Flanges can be assembled and disassembled easily.
Our steel flanges contain prime quality materials. factory-made from quality steel meeting ASTM and/or AISI standards as a result of higher the standard, higher is that the toughness of the ASTM | ASME | ANSI flanges. prime quality of steel content makes an ASTM | ASME | ANSI flanges harder and will increase its hardness. Fastech Global is specialized in Stockists & Supplier of steel flanges in India. Fastech Global may be a certified Stockists & Supplier in India. Fastech Global is wide common in India for its prime quality steel flanges product.
Our purchaser's satisfaction depends on a variety of things like quality, Toughness, Hardness, Delivery Time and our Services for ASTM | ASME | ANSI flanges. Fastech Global may be a Indian suppliers of steel flanges in INDIA. Fastech Global is also a leading supplier and dealer of other flanges such as Stainless Steel Flanges, Alloy Flanges in INDIA. Fastech Global also is a market leader of other products such as ASTM | ASME | ANSI Flange, Stainless Steel pipe and tubes, buttweld pipe fitting, Weld Neck Flanges, Slip-On Flanges and many more other products in INDIA.
Our purchaser's satisfaction depends on a variety of things like quality, Toughness, Hardness, Delivery Time and our Services for ASTM | ASME | ANSI flanges. Fastech Global. may be a Indian suppliers of steel flanges in INDIA. Fastech Global is also a leading supplier and dealer of other flanges such as Stainless Steel Flanges, Alloy Flanges in INDIA. Fastech Global Supplies. also is a market leader of other products such as ASTM | ASME | ANSI Flange, Stainless Steel pipe and tubes, buttweld pipe fitting, Weld Neck Flanges, Slip-On Flanges and many more other products in INDIA.
Typical Design And Dimension
Technical Specification
Nominal Pipe Size |
"A" (O.D.) |
"B" (Thk.) |
"C" (RF Dia.) |
"D" (B.C.D.) |
# Bolt Holes |
Dia. of Bolt Holes |
Approx. Weight |
1/2" | 3-3/4 | 9/16 | 1-3/8 | 2-5/8 | 4 | 5/8 | 2 |
3/4" | 4-5/8 | 5/8 | 1-11/16 | 3-1/4 | 4 | 3/4 | 3 |
1" | 4-7/8 | 11/16 | 2 | 3-1/2 | 4 | 3/4 | 4 |
1-1/4" | 5-1/4 | 3/4 | 2-1/2 | 3-7/8 | 4 | 3/4 | 6 |
1-1/2" | 6-1/8 | 13/16 | 2-7/8 | 4-1/2 | 4 | 7/8 | 7 |
2" | 6-1/2 | 7/8 | 3-5/8 | 5 | 8 | 3/4 | 8 |
2-1/2" | 7-1/2 | 1 | 4-1/8 | 5-7/8 | 8 | 7/8 | 12 |
3" | 8-1/4 | 1-1/8 | 5 | 6-5/8 | 8 | 7/8 | 16 |
3-1/2" | 9 | 1-3/16 | 5-1/2 | 7-1/4 | 8 | 7/8 | 21 |
4" | 10 | 1-1/4 | 6-3/16 | 7-7/8 | 8 | 7/8 | 28 |
5" | 11 | 1-3/8 | 7-5/16 | 9-1/4 | 8 | 7/8 | 37 |
6" | 12-1/2 | 1-7/16 | 8-1/2 | 10-5/8 | 12 | 7/8 | 48 |
8" | 15 | 1-5/8 | 10-5/8 | 13 | 12 | 1 | 79 |
10" | 17-1/2 | 1-7/8 | 12-3/4 | 15-1/4 | 16 | 1-1/8 | 122 |
12" | 20-1/2 | 2 | 15 | 17-3/4 | 16 | 1-1/4 | 183 |
14" | 23 | 2-1/8 | 16-1/4 | 20-1/4 | 20 | 1-1/4 | 241 |
16" | 25-1/2 | 2-1/4 | 18-1/2 | 22-1/2 | 20 | 1-3/8 | 315 |
18" | 28 | 2-3/8 | 21 | 24-3/4 | 24 | 1-3/8 | 414 |
20" | 30-1/2 | 2-1/2 | 23 | 27 | 24 | 1-3/8 | 515 |
24" | 36 | 2-3/4 | 27-1/4 | 32 | 24 | 1-5/8 | 800 |
1/16" raised face included in flange thickness. |
